City – Kochi, India


Kochi, a port city, in the Ernakulam district, in the state of Kerala has an estimated population of 3 million. It is an important port town and houses the Southern Naval Command of the armed forces, the largest International container trans-shipment terminal in India, the Cochin shipyard, and the offshore mooring of the Bharath Petroleum Corporation Limited (BPCL). It is also an important chemical industrial and manufacturing hub and an emerging information technology center in Kerala.

To assess Kochi’s air quality, we selected 40km x 40km domain. This domain is further segregated into 1km grids, to study the spatial variations in the emission and the pollution loads.



Monitoring Emissions Meteorology Dispersion References

Monitoring

We present below a summary of the ambient monitoring data available under the National Ambient Monitoring Program (NAMP), operated and maintained by the Central Pollution Control Board (CPCB, New Delhi, India). In Kochi, there are 7 manual stations reporting data on PM10, SO2, and NO2 and no continuous air monitoring stations.






Satellite Data Derived Surface PM2.5 Concentrations:

The results of satellite data derived concentrations are useful for evaluating annual trends in pollution levels and are not a proxy for on-ground monitoring networks. This data is estimated using satellite feeds and global chemical transport models. Satellites are not measuring one location all the time, instead, a combination of satellites provide a cache of measurements that are interpreted using global chemical transport models (GEOS-Chem) to represent the vertical mix of pollution and estimate ground-based concentrations with the help of previous ground-based measurements. The global transport models rely on gridded emission estimates for multiple sectors to establish a relationship with satellite observations over multiple years. These databases were also used to study the global burden of disease, which estimated air pollution as the top 10 causes of premature mortality and morbidity in India. A summary of PM2.5 concentrations from this exercise, for the city of Kochi is presented below. The global PM2.5 files are available for download and further analysis @ Dalhousie University.

Emissions

We compiled an emissions inventory for the Kochi region for the following pollutants – sulfur dioxide (SO2), nitrogen oxides (NOx), carbon monoxide (CO), non-methane volatile organic compounds (NMVOCs), carbon dioxide (CO2); and particulate matter (PM) in four bins (a) coarse PM with size fraction between 2.5 and 10 μm (b) fine PM with size fraction less than 2.5 μm (c) black carbon (BC) and (d) organic carbon (OC), for year 2015 and projected to 2030.

We customized the SIM-air family of tools to fit the base information collated from the central pollution control board, state pollution control board, census bureau, national sample survey office, ministry of road transport and highways, annual survey of industries, central electrical authority, ministry of heavy industries, municipal waste management, geographical information systems, meteorological department, and publications from academic and non-governmental institutions.

This emissions inventory is based on the available local activity and fuel consumption estimates for the selected urban airshed (presented in the grid above) and does not include natural emission sources (like dust storms, lightning) and seasonal open (agricultural and forest) fires; which can only be included in a regional scale simulation. These emission sources are accounted in the concentration calculation as an external (also known as boundary or long-range) contribution to the city’s air quality.

The emissions inventory was then spatially segregated at a 0.01° grid resolution in longitude and latitude (equivalent of 1 km) to create a spatial map of emissions for each pollutant (PM2.5, PM10, SO2, NOx, CO and VOCs). Below is the gridded PM2.5 emissions and the total (shares by sector) emissions.

Gridded PM2.5 Emissions (2015)

Emissions Inventory

Total PM2.5 Emissions by Sector 2015-2030

Emissions Inventory Emissions Inventory Emissions Inventory

Total SO2 Emissions by Sector 2015-2030

 PM2.5PM10BCOCNOxCOVOCSO2CO2
9,150 16,400 2,250 2,100 63,900 69,550 14,850 20,900 2.40
TRAN 2,650 2,800 1,200 850 6,000 36,450 9,850 3001.45
RESI850850150450450 12,850 1,550 1000.36
INDU 2,550 2,600 300100 51,450 6,250 1,700 20,200 0.28
DUST 1,350 8,350 -------
WAST40045050250- 1,950 400-0.00
DGST600600350100 5,400 1,450 150500.25
BRIC750750200350600 10,600 1,200 2500.05

TRAN = transport emissions from road, rail, aviation, and shipping (for coastal cities); RESI = residential emissions from cooking, heating, and lighting activities; INDU = industrial emissions from small, medium, and heavy industries (including power generation); DUST = dust emissions from road re-suspension and construction activities; WAST = open waste burning emissions; DGST = diesel generator set emissions; BRIC = brick kiln emissions (not included in the industrial emissions)

Meteorology

We processed the NCEP Reanalysis global meteorological fields from 2010 to 2016 through the 3D-WRF meteorological model. A summary of the data for year 2015, averaged for Kochi is presented below. Download the processed data which includes information on year, month, day, hour, precipitation (mm/hour), mixing height (m), temperature (C), wind speed (m/sec), and wind direction (degrees) – key parameters which determine the intensity of dispersion of emissions.



Windrose Functions for 2013-2016

Windrose Functions Windrose Functions Windrose Functions Windrose Functions

Dispersion Modeling

We calculated the ambient PM2.5 concentrations and the source contributions, using gridded emissions inventory, 3D meteorological data (from WRF), and the CAMx regional chemical transport model. The model simulates concentrations at 0.01° grid resolution and sector contributions, which include contributions from primary emissions, secondary sources via chemical reactions, and long range transport via boundary conditions (represented as “outside” in the pie graph below).

PM2.5 Source Contributions Ambient PM2.5 Concentrations PM2.5 Source Contributions

Recommendations

  • Modeled urban average ambient PM2.5 concentration is 29.1 ± 7.6 μg/m3 – is under the national standard (40) and ~3 times the WHO guideline (10)
  • The city requires at least 23 continuous air monitoring stations to statistically, spatially, and temporally, represent the mix of sources and range of pollution in the city (current status – 7 manual and 0 continuous)
  • The modeled source contributions highlight transport (including on road dust), industries (including brick kilns), domestic cooking and heating, and natural sea salt, as the key air pollution sources in the urban area
  • The city benefits from the land-sea breeze, limiting the contribution of sources outside the urban airshed to an estimated 21% of the ambient annual PM2.5 pollution (in 2015) and even less in terms of the absolute contributions
  • The city needs to aggressively promote public and non-motorized transport as part of the city’s urban development plan, along with the improvement of the road infrastructure to reduce on-road dust re-suspension
  • Due to the presence of a large commercial port, the freight movement in and out on the city roads is among the highest in the country, which also leads to emissions from vehicles not registered in the city or the state. The city can benefit from a freight management program to reduce the footprint of emissions from these heavy duty and light duty vehicles, and associated port activities
  • By 2030, the vehicle exhaust emissions are expected to remain constant, if and only if, Bharat 6 fuel standards are introduced nationally in 2020, as recommended by the Auto Fuel Policy
  • By 2030, the share of emissions from residential cooking and lighting is expected to decrease with a greater share of LPG, residential electrification, and increasing urbanization
  • The 250 brick kilns in the urban airshed are fueled mostly by coal, agri-waste, ship bunker fuel, and other biomass. These kilns can benefit from a technology upgrade from the current fixed chimney and clamp style baking to (for example) zig-zag, in order to improve their overall energy efficiency
  • Open waste burning is dispersed across the city and requires stricter regulations for addressing the issue, as the city generates ever more garbage, with limited capacity to sort and dispose of it.
